2600/2600L Series – Process Valve
2600/2600L Series Process Valve
Product Features
| • | Conforms to API 526 |
| • | Full Bore Nozzle Design |
| • | Integral Cast Flanges |
| • | Metal Seat with optional o-ring |
| • | Balanced Bellows option |
| • | Open Bonnet and Lever Assemblies option |
| • | Adjustable Blowdown |
| • | 2600L – Multiple Service Single Trim Design option |
Description
2600/2600L Series Process Valve
General Specifications
Size
- 1” x 2” to 20” x 24”
Orifice Areas
- D (0.15in2) to Z (176.7 in2)
Set Pressure Ranges
- 15 to 6000 psig (1.0 to 413 barg)
Temperature Ranges
- -320 to 1500°F (-195 to 815°C)
Flange Classes
- 150# – 2500#
Suitable for
- Air, Gas, Vapor, Steam & Liquid Service
Materials of Construction
- Carbon Steel
- Stainless Steel
- Low/High Temperature Alloy Steels
- Monel
- Hastelloy C
- Duplex
- NACE Compliant Materials
Certifications
-
ASME/NB Section VIII and III for Air, Steam and Water -
CSA B51 (Canada CRN)
-
ISO 9001- 2008
-
PED 97/23/EC (European Pressure Equipment Directive)
-
ATEX 94/9/EC (European Potentially Explosive Atmospheres)
-
CSQL (China)
-
GOST-R (Russian)
-
US Coast Guard
-
Nuclear – 10 CRF 50 Appendix B, NCA-4000, NQA-1 N285.0
-
